【E1】ESP32 Development Board

[Multiple Functions]: The ESP-WROOM-32 development board integrates a variety of peripherals, including capacitive touch sensors, Hall sensors, low noise amplifiers, SD card interface, Ethernet interface, and high-speed SDIO/SPI, UART, I2S, I2C, etc. [High Performance]: The ESP32 HAT features a powerful dual-core CPU, enabling it to deliver exceptional performance for wireless WiFi and Bluetooth connectivity applications. [Wireless Connectivity]: With built-in WiFi and Bluetooth capabilities, the ESP32 dual cores microcontroller allows seamless and reliable wireless communication, making it ideal for IoT projects and smart device control. [Energy Efficient]: The WiFi + Bluetooth module is designed to be highly energy efficient, ensuring long battery life and reducing power consumption,

Connectivity Technology：Bluetooth, Wi-Fi, USB

Included Components：3 x ESP32 CP2012 USB-C (Type-C) Development Board Module

CPU Manufacturer：Espressif

Additional Information：

Our team focuses on the design, development, and production of electronic products, especially in the field of embedded systems. Our products involve fields such as microcontrollers and embedded development boards, such as for Jetson Nano, for Arduino, for Raspberry Pi, for ESP32/ESP8266, for STM32, etc.We value product quality and customer experience, striving to provide customers with the highest level of after-sales service.

About this item

[Multiple Functions]: The ESP-WROOM-32 development board integrates a variety of peripherals, including capacitive touch sensors, Hall sensors, low noise amplifiers, SD card interface, Ethernet interface, and high-speed SDIO/SPI, UART, I2S, I2C, etc.
[High Performance]: The ESP32 HAT features a powerful dual-core CPU, enabling it to deliver exceptional performance for wireless WiFi and Bluetooth connectivity applications.
[Wireless Connectivity]: With built-in WiFi and Bluetooth capabilities, the ESP32 dual cores microcontroller allows seamless and reliable wireless communication, making it ideal for IoT projects and smart device control.
[Energy Efficient]: The WiFi + Bluetooth module is designed to be highly energy efficient, ensuring long battery life and reducing power consumption, making it suitable for low-power applications and portable devices.
[Easy Integration]: The ESP-32S board is compatible with a wide range of development platforms and programming languages, facilitating easy integration into existing projects and reducing development time.

AI Acceleration Support

ESP32-S3 has additional support for vector instructions in the MCU, which provides acceleration for neural network computing and signal processing workloads. Developers can take advantage of these vector instructions through ESP-DSP and ESP-NN libraries to optimize their applications. ESP-WHO and ESP-Skainet SDKs will also support this acceleration.

Wi-Fi + Bluetooth 5 (LE)

ESP32-S3 supports a 2.4 GHz Wi-Fi (802.11 b/g/n) with 40 MHz of bandwidth support. The Bluetooth Low Energy subsystem supports long range through Coded PHY and advertisement extension. It also supports higher transmission speed and data throughput, with 2 Mbps PHY. Both Wi-Fi and Bluetooth LE have superior RF performance that is maintained even at high temperatures.

Rich Set of IO Peripherals

ESP32-S3 has 45 programmable GPIOs, SPI, I2S, I2C, PWM, RMT, ADC and UART, SD/MMC host and TWAI^TM. In total, 14 GPIOs can be configured as capacitive touch input for HMI applications. Apart from all these peripherals, however, ESP32-S3 is also equipped with an ultra-low-power (ULP) core that supports multiple low-power modes in a variety of such use-cases.

Security

ESP32-S3 provides all the necessary security requirements for building securely connected devices, without requiring any external components. It supports AES-XTS-based flash encryption, RSA-based secure boot, digital signature and HMAC. ESP32-S3 also has a “World Controller” peripheral that provides two fully-isolated execution environments, which enables the implementation of a trusted-execution environment or a privilege-separation scheme.

Mature Software Support

ESP32-S3 is supported through Espressif’s popular ESP-IDF platform that already powers millions of devices on the market. ESP-IDF comes with rigorous testing, regular updates and an unparalleled support policy. Based on ESP-IDF’s mature software architecture, developers can easily build applications anew or migrate their own applications to the ESP32-S3 platform, and continue working with the trusted ESP-IDF tools and APIs.
