3-Axis Robotic Arm Automated Factory Demonstration Teaching System

This 3-axis robotic arm automated factory demonstration and teaching system can read 3-axis coordinate values via the upper computer and generate GCODE execution commands. Corresponding GCODE commands can be produced according to different acquired coordinate values to enable the robotic arm to execute various motion groups. Meanwhile, switch commands for air pumps and conveyor belts can be embedded to construct an automated working scenario. In addition to the teaching function, the robotic arm adopts high-torque planetary reduction stepper motors and is paired with a conveyor belt with a 5 kg load capacity, capable of practical industrial automation applications under light-load conditions.

   Full aluminum alloy 3-axis robotic arm Planetary reduction stepper motors Three travel limit switches

   Optional single-head, double-head, four-head vacuum suction cups; Optional rigid or flexible clamping grippers at the end effector. Upper computer control program supports flexible editing of GCODE e

   85mm×460mm stainless steel conveyor, load capacity: 5KG; 600mm×600mm aluminum profile frame base, anti-static top panel; Mini host i3-4130 / 120G SSD / 8G RAM, equipped with WIFI, Bluetooth, keyboard
